Metabo | Planer Thicknesser DH 330

by Metabo
SKU 0200033000
Sold out
Original price R 12,999.00
Original price R 12,999.00 - Original price R 12,999.00
Original price R 12,999.00
Current price R 11,139.00
R 11,139.00 - R 11,139.00
Current price R 11,139.00

"Sharp blade fit for cutting soft woods only."

  • Ideal for mobile use due to low weight
  • Stable gear for uniform work piece feed
  • Convenient height adjustment with crank handle
  • Easy setting of common passage heights using stop points
  • Powerful universal motor for powerful lugging drive and even planing result
  • Restart protection: prevents unintentional start-up after power supply interruption
  • Precise thickness adjustment for quick and exact planing
  • Large feed and exit tables support the conveyance of long materials
  • Planing locking mechanism prevents unintentional adjustment of the chip removal setting
The machine shown may differ in equipment and technical details depending on the configuration.


Specifications

  • Dimensions: 579 x 857 x 574mm
  • Chip removal bench thicknesser: 0 - 3mm
  • Material thickness table: Cast aluminium / special steel aluminium
  • Thickness table L x W: 840 x 330mm
  • Passage height/width: 152 / 330mm
  • Feed rate: 7m/min
  • Diameter of blade shaft: 47mm
  • Number of blades: 2
  • Revolutions of blade shaft: 9800rpm
  • Mains voltage: 220 - 240V
  • Rated input power: 1800W
  • Weight: 35kg
