Einhell Germany AG
A centre for ideas, quality and innovation
The Einhell TE-SM 36/210 Li drag, crosscut and mitre saw can be used with flexibility for all woodworking jobs, for cutting miter cuts and for cross-cutting and even cutting parquet to length. The cordless version of the saw provides an unlimited radius of
operation: No interfering cables while working, no rewinding when the job is done. As a member of the Power X-Change series, all the rechargeable batteries from the high-performance lithium-ion series can be combined with the drag, crosscut and mitre saw.
For optimum results it is recommended that a 2,5Ah Plus rechargeable battery from the PXC series be used as a minimum. This is available separately. The Einhell drag, crosscut and mitre saw is equipped with a smooth draw function which is suitable for wider workpieces. The X-Tend workpiece supports can be adjusted with one hand and without the need for any tools. The clamping device is for holding the workpiece securely in position.
The turntable has a precise angle adjustment facility for angular cuts. In addition, the saw head can be tilted up to 45° to the left for mitre cuts. The high-performance saw has a high-quality carbide-tipped precision saw blade developed specially for cordless saws and delivers a fine cut. A cutting line laser and an LED light ensures that cuts can be made quickly, accurately and above all safely. The cordless drag, crosscut and mitre saw also has a sawdust bag or an adapter for an extractor, for keeping both the workplace and the air clean.
- Member of the Power X-Change family
- Boundless reach of action, no annoying cable, nothing to wind
- A smoothly running drag function for wide workpieces
- Turntable with precise angle setting for angular cuts
- Saw head tilts up to 45° to the left for miter cutting
- X-Tend work supports with ergonomic single hand operation facility
- High-grade precision saw blade, developed for cordless mitre saws
- Laser and LED for easy and safe use
- Clamping device for holding the workpiece securely in position
- Incl. sawdust bag to keep the workplace clean
- Supplied without battery and charger (available separately)
- Recommendation for best results: 2,5Ah Plus batteries or higher
Specifications
| Cutting depth 45° x 45° |
35mm |
| Cutting depth 45° x 90° |
35mm |
| Cutting depth 90° x 45° |
65mm |
| Cutting depth 90° x 90° |
65mm |
| Cutting width 45° x 45° |
210mm |
| Cutting width 45° x 90° |
310mm |
| Cutting width 90° x 45° |
210mm |
| Cutting width 90° x 90° |
310mm |
| Idle speed max. |
3800rpm |
| Motor voltage |
36V |
| Number of batteries included in delivery |
0 pcs |
| Number of chargers included in delivery |
0 pcs |
| Product weight |
12,57kg |
| Suction connection diameter |
35mm |
Everything visible at a glance
- The laser marks out the cutting line where the later cut is to be made. The LED light ensures that the working area is perfectly lit.
Flexible in any position
- The saw head of the cross-cut mitre saw can be tilted up to 45° to the left: This means mitre cuts in a wide variety of positions are no problem.
Just do it yourself!
- The high-quality die-cast aluminium turntable has precise locking positions at the most common angles for classic DIY work.
Precision in every situation
- The extendable X-Tend workpiece supports on the left and right provide support for precise and flexible work with longer workpieces.
